LED Glass Tube 9W G13 600mm NW Papertube 120lm/W
Product code: AB600T8-9W-NW-GL-IL-1
9 W
1 080 lm
4 000 K
600 mm
Product Support
In case you have any questions about our products or requests please feel free to contact us.
EAN
5999097925721
Bulb shape code
T8
Lifespan
25 000 h
Output current
0.12A
Changeable Color Temperature
No
Technology
LED
Rated current
80mA
Socket
G13
Power
9 W
Equivalent wattage
30 W
Length
0,6 m
Voltage range
180-265 V
Output Voltage
46 V
Working temperature
-20 - +40°C
IP Class
IP20
Diameter
26 mm
Length
600 mm
Width
26 mm
Height
600 mm
Depth
26 mm
Color temperature
4 000 K
Lumen output
1 080 lm
Lumen/Watt
120 lm/W
Color temperature
NW
Beam angle
240 °
Chip type
SMD
Color rendering index
80
Dimmable
No
Power factor
0.5
No information
CTN
85395200
Packaging size
30mm x 30mm x 645mm
Weight
120 gram
Gross volume
1 524,1 cm³
Carton EAN
5999097925738
Pcs / carton
25
Carton size
690mm x 233mm x 237mm
Detailed description
The Avide LED dust- and moisture-proof fixtures for tubes represent the energy-saving versions of traditional fittings. The fixtures of different lengths replacing the tube fixtures have a built-in LED panel that guarantees energy-saving operation. In terms of the material used, the products have a break-resistant cover. Due to the IP65 protection of the fixture, it is protected from dust and moisture, thus can also be operated at places with higher exposure to dust and humidity.
The product range includes a 1 and 2 LED design, in lengths of 0.6, 1.2 and 1.5 meter lengths, with a transparent cover.
OUR IP protected fixture category includes numerous additional products. Learn more about these on the following link.
Downloadable documents
Power Consumption Calculator
Average annual consumption
LED Glass Tube 9W G13 600mm NW Papertube 120lm/W
Power
9 W
Hour / day
Day / week
kWh Price
Annual operation time: hour -
Energy Consumption (kWh): kWh -
Energy cost: EUR -
